Canning Beer

Share:

Function: Filling beer in cans then sealing cans.
Model: GDF18-6 ( Filling head:18 Sealing head:6)
Capacity: 2000-4000CPH
Packaging Type: 200-2000ml aluminium cans
Machine material: SUS 304/316L
Overall size (L*W*H): 2100*1650*2200mm
Weight: 2000KG
Certificate: CE ISO SGS
Warranty: 3 Years

Product Description

Canning Beer

The canning beer machine is used for filling beer in cans and sealing cans. It's designed on the basis of absorbing domestic and foreign advanced technology. It has such advantages as advanced construction, stable working, convenient operation and repair & maintenance, transducer control as well as high production efficiency. It is the ideal equipment for mid-scale & small-scale beer factory.


Empty Aluminum Can Rinsing System

Canning Beer


Overall view of Canning Beer

Canning Beer


Front View of Canning Beer

Canning Beer

Canning Beer


Filling Part of Canning Beer

Canning Beer

Can Filling Part:

1).304/316 Stainless steel high-accuracy mechanical filling valves.

2).304/316 Stainless steel fine polish filling tank without death corner.

3).Isobaric filling principle.

4).Filling with cans and no filling without cans.

5).High accuracy of liquid level

6).Liquid level in filling tank is controlled via float-ball.

7).The height of the filling tank can be adjusted to fit the different height of cans.


Sealing Part of Canning Beer

Canning Beer

Sealing Heads of Canning Beer

Canning Beer

Can Sealing Part:

1).Adopts Taiwan sealing roller and pressure head technology to make sure the quality of sealing.

2).The control system of dropping lid with can and no dropping lid without can reduce lids loss rate.


Reference Sheet Of Canning Beer Series Equipment :

ModelGDF12-1GDF18-6GDF24-6GDF32-8GDF40-8
Filling/Sealing heads12-118-624-632-840-8
Capacity: CPH1000-20002000-40004000-80008000-1200012000-15000
Filling precision≤±5mm (Measure after the liquid level is stable)
Power (KW)1.73.54.55.26.5
Overall size (mm)1600*1300*22002100*1650*22002350*1750*22002800*2200*22003200*2400*2350
Weight (KG)15002000280040004500


For more details & info. of the Canning Beer Machine,welcome to enquire now.
